Welcome to part 6 in the Apple ][ plus repair series. In this video, I'll take a look at the expansion cards in this system including the Videx VideoTerm 80 column card and the Microsoft Z80 Softcard. I'll service the two disk drives that came with this machine.
Part 1: https://youtu.be/qTkX7rkq_Kk
Part 2: https://youtu.be/1iCLdbF1sgw
Part 3: https://youtu.be/pkxs-180IKU
Part 4: https://youtu.be/wVUWaodwNNI
Part 5: https://youtu.be/984mZex2pKY
Part 6: This part!
0:00 Intro
0:49 Testing the Videx 80 column card clone
4:32 Making a Videx video cable
8:55 Videx 80 column card demo -- medium res text mode graphics?
13:00 Apple II font editor
14:43 Testing the Microsoft Soft Card (Z80 CP/M card for the Apple ][)
17:48 Servicing the Apple ][ disk drives
27:07 Outro
