To install the cruise control yourself, you will need the following tool:
Torx T30, T20, T8, Spline M12, hex 5, wrench 10
==============================
To activate the cruise control function, it is necessary to change the coding of the engine control unit and steering wheel using the Vag-Com diagnostic cable
01 - Engine - Coding - Long coding - Byte 6 Bit 0 - Change 0 to 1
16 - Steering wheel - Coding - Long coding - Byte 2 Bit 2 - Change 0 to 1 or select 04 cruise control installed
To adapt the steering angle sender G85:
16 - Steering wheel - Login - 16 (Security Access) - code 40168 - Basic settings 04 (Basic Settings) - Channel 001 - and press start (GO)
Turn the steering wheel at least 30 ° left and right, return the steering wheel back straight to 0 ° (tolerance: ± 5.0 °)
Activate the basic setting, for this, press the ON / OFF / Next button 1 time, after a successful basic setting, in field 3 there should be "OK", to exit press Done, Go Back
==============================
Articles of steering column switches and rings:
Kostal:
- 8K0 953 568 D or J - does not support CC, does not support multifunction
- 8K0 953 568 E or K - supports CC, does not support multifunction
- 8K0 953 568 F or L - supports CC, supports multifunction, does not support Adaptive Cruise Control
- 8K0 953 568 G or M - Supports CC, Supports Multifunction, Supports Adaptive Cruise Control
VALEO
- 8R0 953 568 H - does not support CC, does not support multifunction
- 8R0 953 568 J - supports CC, does not support multifunction
- 8R0 953 568 F - supports CC, supports multifunction, does not support Adaptive Cruise Control
- 8R0 953 568 M - Supports CC, Supports Multifunction, Supports Adaptive Cruise Control
You can check without disassembling which steering wheel ring is installed using vag com in block 16 - Steering wheel
The article of the purchased switch with cruise control is 8K0953502BK, in catalogs it goes with the color code 8K0953502BK4PK
==============================
Timecodes:
0:00 Start
1:07 How to tell if cruise control is supported
1:36 Tool required to install QC
2:19 Removing the airbag
3:52 Removing the steering wheel
5:22 Removing the cover
6:29 Removing the steering column switch
7:27 Removing the steering wheel rotation sensor ring
9:40 Comparison of version E and F
10:53 Steering wheel and engine block coding
13:51 Adaptation of the steering wheel sensor G85
15:01 Cut a hole in the lower casing
15:42 Possibility to connect separately the CC handle to the old switch
16:17 Finished result of cruise setting
17:06 How to use cruise control
18:30 Using the cruise on the move
==============================
