CX500 Build - Rae San Hall Effect Ignition Install / HOW-TO - EP48

It is time to get the ignition side of things done on the CX500 build with a nice kit from Rae San in Australia. This is the hall effect kit for the GL650 engine which has pre-programmed ignition curves built into it to allow the removal of your old spring actuated advance mechanism. There are many kits available from Rae San so this kit may not be the exact unit you have but the installation will be similar regardless. My goal was to make this a very clear video with detailed views of the flywheel markings and how/why you set the pickup plate the way you do. Be sure to follow along as this bike nears completion!

Note: I did update this video as I gave incorrect information on setting the timing so I revised it to be accurate. Thank you to those who let me know!

Rae-San Ignition website:
https://www.rae-san.com/

Motofaction install information:
https://motofaction.org/motorcycles/honda-cx-gl/a-how-install-guide-rae-san-hall-effect-aftermarket-ignition-cdi-replacement-cx500-gl500-cx650-gl650/

Ignition Coil Used:
https://www.ebay.com/sch/i.html?_from=R40&_trksid=p2334524.m570.l1313&_nkw=ultima+53-434+coil&_sacat=0&LH_TitleDesc=0&_osacat=0&_odkw=ultima+53-434

NUUT Morty PDM shown:
https://nuut.ca/morty2x/
