Answers to most questions about The BEAST, the most crazy #powersupply on steroids: characteristics; why so many transformers; transistors used (and dead); and more...
This video is a follow up of a previous video where I shown how I built this beast. (See link below)
It is a multi output power supply for the #electronics #lab.
It features four galvanically isolated power supplies in one single box, and with isolated external control voltage inputs.
Two variable outputs, one of them up to 60V, and two selectable fixed voltages designed for supplying low power analog and digital circuits.
How I built it? Watch the video: https://youtu.be/vEN0uJqn0ko
More information on https//accidentalscience.com
Technical details on my website at: https://accidentalscience.com/19/The%20Ultimate%20Power%20Supply.html
