🚀 Welcome back to our Automation Avenue! 🤖 In today's video, we're delving into the world of HMI alarms in Siemens TIA Portal. Before you can showcase alarms on your HMI, it's crucial to establish a comprehensive list of alarms in the PLC. Join me as we seamlessly link these alarms to the HMI, enhancing the functionality of your automation setup.
Consider a system with motors and sensors — imagine having alarms for motor breaker trips and sensor-related issues like high and low value alarms. Today, we'll be creating a simulated environment using a simple ladder program and buttons to trigger these alarms. Although we don't have actual breakers and sensors, this simulation will guide you through the essential steps.
🛠️ Topics Covered:
Creating a list of alarms in the PLC.
Linking alarms to the HMI for real-time monitoring.
Simulating motor breaker trips and sensor-related alarms with a ladder program and buttons.
