This is my take on how to create and cut a US Flag on a CNC that includes a logo. I walk through the milling, glue-up, sanding and everything else to make a good large flag. Then I walk you through using Vectric VCarve Pro to set up all the cut files for the CNC. The video shows the entire CNC milling process with some tips and tricks and then moves on to cutting Keyhole slots for hanging and a CO2 lasered message on the back. Hope you find this woodworking/CNC/painting/computers/lasering video helpful!
Blog Article With Links!!!
https://hillcountrycnc.com/how-to-make-a-cnc-flag-with-logo/
Timecodes
0:00 - Intro
0:15 - Dimensioning Lumber
4:10 - How I Glue Up Material for a Wooden Flag
6:25 - How to Apply Oramask Application
8:05 - How to Size & Import Vectric VCarve Pro Tutorial
10:45 - How to cut Field of Stars Cut Out Vectric VCarve Pro Tutorial: Bit Amana Tools RC-45711
12:13 - How to Import & Embed Logo Vectric VCarve Pro Tutorial
14:03 - How to Cut Set-Up Logo Vectric VCarve Pro Tutorial: Bits Amana Tools 45626k & 46200k
16:21 - How to Set-Up Flag Stripes Vectric VCarve Pro Tutorial: Bit Amana Tools 46202k
18:27 - How to Cut Out a Flag Vectric VCarve Pro Tutorial: Bit Amana Tools 46202k
20:32 - How to make a Oramask Cut Out Vectric VCarve Pro Tutorial: Bit Amana Tools 46200k
23:04 - Oramask CNC Cut Out using Onefinity Journeyman X-50 CNC
24:14 - Logo CNC Cut Out
27:53 - Field of Stars CNC Cut Out
29:54 - Stripes CNC Cut Out
32:36 - Flag CNC Cut Out
33:33 - Vectric VCarve Pro Tutorial (Keyhole Set-Up) Bit Amana Tools 45626
43:04 - OMTech Laser etching
