Modular Hogwire Panel Fence with Dado Groove
** For access to construction plans and cost generator you can copy the dropbox link: https://www.dropbox.com/sh/izf2e5qpiehb3ww/AAAePDHhimVmyO2n4fJ-l2mva?dl=0
Contact Info:
Email- gator.overland@gmail.com
Facebook- https://facebook.com/JKHartel3
Instagram- @gator_overland
**See recently uploaded Part 2, which includes and 18 month evaluation and stain tutorial***
https://youtu.be/bL89wkzSPDo
•Wire panel cut dimensions: L= 92" H= 48" trimmed from 16ftX5ft 6ga. utility/hog panel w/ 4x4 square mesh. (Makes 2 panels per sheet) see Tractor Supply Co.
•Panel frame completed overall dimensions: 93.5"x49.25"
•Panel frame cut lengths: Frame Top/Bottom*= 93.5" Vertical Sides=46.25" (3ea- 8ft 2x4's required per panel frame)
*All panel frames were constructed per the cut lengths listed above except for the (3) panel frames that the top and bottom lengths were shortened to account for a gate (referenced in the video).
•Dado width @ 3/8" & cut depth set @ 1"
•8ft 4x4 Post @ 24" depth w/ 3" of gravel and centers set @ 97" apart.
•3.5" #9 outdoor/deck screws (approx. 400 screws used)
•(1) 10ft & (2) 4ft panel gates (see Tractor Supply Co.)
•(3) Speeco 2 way gate latch (see Tractor Supply Co. & Amazon)
I have a PDF construction details w/ dimensions and material breakdown as well as an excel estimate generator that I developed based on my exact build per ft. that you can access from this dropbox link
Construction PDF Dropbox Link- if you’d like access to my DIY schematics/diagrams, there’s a small $5 access fee. You can send it via Venmo, paypal or cashapp
After sending payment, just screenshot your confirmation and email it to gator.overland@gmail.com , and I’ll send the drop box link. Thank you for supporting my work.
Venmo- @john-hartel
PayPal- @gatoroverland
Cashapp- $johnhartel
jkhartel3@gmail.com **its been 6 years since posting this video and im still sending my construction details to hundreds of people**
Thanks for watching, like/subscribe and I hope you enjoy your fence. Description updated 5/2020
