Software: Rhino 6
In part two of this practical Rhino CAD tutorial, we look at one way to create a tapered bezel setting for the oval gemstone we made in part one.
As well as the how I’ll also be explaining the why, breaking down my decision making process along the way.
Presented and narrated by Jack Row FIPG.
Any questions, post them in the comments section.
Project resources download link (used in Part One): https://drive.google.com/…/1XSNEN0QsF2l4qLOfvdung7O_OUniubvr
If you'd like to discuss booking a 1to1 bespoke CAD lesson or have any other business enquiries, send me an email: jack@jackrow.com
Software link:
Rhino 3D - https://www.rhino3d.com/download - Free 90 day trial currently available at time of posting.
Featured key Rhino commands in this video include:
• Offset Curve
• Extrude Curve Straight & Tapered
• Shell
• Clipping Plane
• Chamfer Edge
Top tip in this Video:
Make sure the angle of your bezel setting is sympathetic to the shape of your stone’s pavilion.
