Reducing stress concentration through shadowing: parametric study in FreeCAD FEA

Did you know that you can add a notch next to a notch, and reduce the stress concentration factor in a part? In this video I give a demonstration of this effect using a parametric finite element analysis set up in FreeCAD.

You can download the freecadparametricfea library via pypi https://pypi.org/project/freecadparametricfea/

Want to get involved? Contribute on Github at https://github.com/da-crivelli/freecad-parametric-fea/

Buy me a coffee if you want to support the channel :) https://www.buymeacoffee.com/dacrivelli

Timestamps:
00:00 Intro to notch effect and notch shadowing
04:15 Model setup in FreeCAD
15:20 Setting up the parametric study
20:10 Full results

If you want to get involved, do get in touch!
