With demonstrations using a function generator and TI SN75176B transceivers …
↓↓↓ Complete description, time index and links below ↓↓↓
In late 2021 I covered the RS-422 basics and details in six videos (links below). Now let’s talk about RS-485, which kinda is an evolution, respectively, extension of RS-422. Stuff already explained in the RS-422 videos will not be repeated in this series.
First we have a look at my bench, where a 1MHz logic level square wave is transmitted as differential signal using two RS-485 transceivers. Then we talk about bus topology, specification and performance. Finally we turn things up to 10MHz.
00:00 Intro – RS-485 kinda is an evolution/extension of RS-422
01:11 Principles – eerily similar to RS-422, but slightly different
11:13 Topology – RS-485 is a bus, RS-422 is point to (multi) point
15:00 Specification – differences to RS-422, TI SN75176B datasheet
22:53 Performance – speed vs distance and number of transceivers
XX:XX Wrap-up – next we’re using RS-485 with an Arduino MCU, bye
