==Ocelot Tuner Studio Settings==
Board type is UA4C
Onboard MAP sensor is an mpxh6400a
Onboard Barometric sensor is an kp234 and is on pin A7
==Ocelot Jumper Settings==
first jump your primary/secondary jumpers to either 'tsc' (vr) or 'direct' (hall)
-Secondary trigger config is closest to the edge of the board
-Primary trigger config is closest to the VR conditioner headers
next, if using hall, you likely need to jump the 'pull up resistor' for the given primary/secondary trigger
==Pinout for ocelot==
https://github.com/turboedge/SpeedyBoards/blob/master/OCELOT/DOC/Ocelot%20Connector%20Mapping.pdf
==Drivers for ocelot==
https://www.silabs.com/documents/public/software/CP210x_Windows_Drivers.zip
==3d printed case==
https://www.printables.com/model/1013210-speeduino-ocelot-simple-case
Ocelot is a Speeduino based ECU that is being sold by WMTronics.com. This is not a sponsored video, I purchased this ECU with my own money because I wanted to try it out. This video is a boiled down reaction/how to video for operating this ECU.
The Speeduino community is filled with great people who have helped me figure out how to at least get my jeep running, and hopefully ill be an actual tuner soon because of the community help. I simply hope I can give something back to the community with this video.
