In this video, I’m working on fabricating custom rear upper shock mounts while following along with the King of the Hammers race coverage. Watch as I design, cut, prep, and weld these shock mounts, using tools like a plasma cutter, file, TIG welder, and even a slip roll. The process includes tackling challenges like cleaning plasma-cut edges, achieving precise fits, and creating strong welds. Stick around to see the final product ready to be mounted on the buggy.
0:00 Intro
0:36 King of the Hammers setup and rear shock mount design explained
1:06 Breaking down material choices and overlay setup
3:30 Prepping materials and cleaning plasma-cut edges with vinegar
5:02 Using tools to prep and clean metal edges
6:05 Tackling tight corners with files and weld prep tips
10:19 Tacking the pieces together and handling the spine section
12:37 Rolling radii with the slip roll for precise fits
15:46 Adjusting and aligning the pieces for tack welding
21:05 Detailing more fabrication and overlay tack welding
23:13 Tackling boxing pieces and fitting them accurately
27:20 Clamping parts and aligning weld points
30:12 Measuring and cutting flat bar for boxing the mounts
33:20 Ongoing welding progress and technique reflections
36:03 Final welding touches and review of the mount
37:31 Reflecting on the build process and improvements to make
38:40 Final product reveal and closing thoughts
If you enjoyed watching or picked up some useful tips, make sure to like, comment, and subscribe for more fabrication projects!
