A shortwave SDR receiver using a Tayloe Quadrature Detector. Costs less than $15 and can be built with few parts on a breadboard or a PCB.
Get your PCB from PCBWay: https://www.pcbway.com/?from=Doctor%20Volt
All you need to replicate: https://github.com/michalin/easysdr
Quisk SDR software: https://james.ahlstrom.name/quisk/
Paper on Tayloe Quadrature Mixer: https://www.norcalqrp.org/files/Tayloe_mixer_x3a.pdf
Recommended USB soundcard:
USB Audio Adapter, 96 kHz/24-Bit Hi-Fi: https://amzn.to/3tLdLtU
Please use this links for your order to support the channel. It's the same price for you, but I get a small commission.
Consider supporting this channel and get updates about ongoing projects and ad-free preview videos!
Become a Patron: https://www.patreon.com/docvolt
Or make a single donation per Paypal: https://www.paypal.com/paypalme/docvolt
00:00 - Introduction
00:20 - What is software defined radio, how does it work?
01:20 - Mirror frequency problem
01:53 - Quadrature demodulation
03:12 - The Tayloe Quadrature Detector
06:18 - Quisk SDR software
08:01 - First tests
09:25 - Building on PCB
10:34 - Clock generator Si5351
11:32 - Chasing for waves
