Types of Shaft Couplings:

1. Rigid Coupling
A. Muff/Sleeve Coupling B. Split Muff/ Compression Coupling C. Flange Coupling ( Unprotected, Protected, Marine Type Flange Coupling )

2. Flexible Coupling
A. Bush Pin Type Flexible Coupling
B. Universal Joint/ Coupling
C. Oldham Coupling


1. Muff/Sleeve Coupling Animation
https://youtu.be/Lwnv_cg5AqA

2. Split-Muff Coupling Animation
https://youtu.be/b5KpbwpNQXA

3. Unprotected, Protected, Marine Type Flange Coupling Animation
https://youtu.be/DjcP0W_NpM0

4. Bush Pin Type Flexible Coupling Animation
https://youtu.be/vZjfJrihzyg

5. Universal Joint
https://youtu.be/nC9Zn2ol2ek
