My Custom 3D-Printed 5-Inch FPV Drone - Full Build Walkthrough. "No-Talking-Just-Building"
STL files available on Vixen Printz Thangs (link in Bio).
Frame is available for both 20 x 20 and 30 x 30 stack mounting options.
For 30 x 30 stack builds, use different stack components (from the ones listed below) accordingly.
The following has been excluded from this walkthrough:
- Betaflight Configurator Setup (Filters, PIDS, GPS, Motor Direction, FC Orientation, etc.)
- DJI O3 FPV Camera to Goggles Binding
- ELRS to Radio Reciever Binding
Let me know in the comments if you'd like me to cover the above excluded details.
If there's enough interest, I'd be happy to create a series of walkthrough videos to dive deeper into those topics.
Parts List:
Flight Controller - Mamba 4th Gen MK4 F722 Mini
Electronic Speed Controller - FOXEER REAPER SLIM 60A ESC
Receiver - Foxeer ELRS 2.4G Receiver LNA V3.2.1
Battery - Tattu R-Line 6S - 1200 mAh Lipo Battery XT60
Motor - 4 x T Motor F60 PRO IV 2.0 1950 kv
Propellor - 4 x HQ Prop Ethix S5
FPV Camera - Dji O3 w/ Stubby Antenna
GPS - MATEKSYS SAM-M8Q
Action Camera - Dji Action 2 w/ ND Filter
Frame - 3D Printed PET-CF (Bottom Frame w/ Upper Saddle)
Mounts - Transparent TPU (Motor Skids, Action Camera, FPV Camera, FPV VTX, ELRS RX)
Other
- Screws (Stack, Motors, FPV Camera, Action Camera, Standoffs)
- Standoff - 25mm M3 Smooth Hex
- Racewire - 4 x RGB RACELITEWIRE
