At our workshop, we manufacture and sell speaker boxes.
We occasionally list them on Yahoo Auctions. Currently listed as of 2024/12/27.
https://auctions.yahoo.co.jp/sel...
★ Sold. Thank you very much.
■Specifications
Height: 600mm
Width: 325mm
Depth: 334mm
- Combination of front-loaded horn and bass reflex
- Exterior finished with cherry veneer
- Horn finished with Honduran mahogany veneer (neither of which are stained, only clear coated)
- The original material is all "laminated plywood"
■Steps to Make Front Loaded Horn Speakers
00:00 Wood Selection
Cut slightly larger than the finished dimensions.
1:20 The adhesive is water-based emulsion.
It tends to cause poor adhesion if it is too thick.
2:03 Lamination
Laminate "veneer plywood" on both sides of the core plywood.
3:47 Press with woodworking press machine.
Laminating the plywood increases both strength and accuracy.
4:20 Cut to exact dimensions.
5:18 Finish the edges.
6:47 Cut veneer for the horn.
The mahogany veneer for the horn is thick and not backed.
9:50 Press the veneer.
12:07 Cut the baffle board.
12:31 Cut circles with a circle cutter.
14:57 Assembled horn.
15:19 Biscuit joint.
Glue alone is enough to provide sufficient strength.
17:12 Assembly
The press for this assembly is powerful.
17:55 Finishing
Wipe the entire surface with water and then adjust with fine paper.
Moistening with water restores fine scratches.
19:18 Completion.
