Hello Guys,
This is an instructional video to help you new Voodoo Lab users do a quick setup of your devices and control what MIDI patches are activated.
My setup was using Loop1 to swap between a Peavey TubeFex and a Mesa Boogie Triaxis preamp.
MIDI channel 1 is the triaxis
MIDI channel 2 is the tubefex
you can set these up to be any channel 1-15 you just have to set them up the same on the devices as you choose on the ground control.
to get into the area to do this hit the left and right setup buttons on the ground control at the same time. this takes you into the setup on part 1. this is where you name and set the device channels you want each device to talk to on MIDI.
part 2 is to configure the pedal/patch to what channels for each device to switch to and which of the gcx loops to be active. so if you want to put an individual chain of pedals or an effects processor in it's own loop to use for both amps you can here. then you can have it active or inactive for each patch pedal. you can also name the patch on the lcd here.
this is the basic and quick way to set one up.
hopefully this helps out.
I will post the wiring I did here later tonight on the actual preamp to gcx switch since that was the only thing I didn't actually talk about in the video.
The MIDI cable from the GCX goes into the MIDI Out of the floor controller. I told you guys wrong in the video so ignore that part.
